Automatic safety shutdown
High-speed data acquisition
Fully programmable testing modes
Touchscreen interface with remote access
System A
Oilgear Pump
Lincoln Motor
Complete Pressure Adjustment (450 - 5000 PSI)
Complete Flow Adjustment (0 - Full GPM)
Pressure and Return Ports
Digital Pressure Gauges (.25% Accuracy)
Digital Supply and Return Flow Meters (1% Accuracy)
Safety Over Pressure Relief Valve
By-Pass Dump Valve
Pump Flow Control Valve
Pump Pressure Control Valve
Super Clean Filtration
System A & B High Efficiency, Non-Bypass Pressure Filters (3 Micron Absolute)
Reservoir Kidney Loop Filter (3 Micron Absolute)
Sink Drain Filter (3 Micron Absolute)
Reservoir Fill Pump Filter (3 Micron Absolute)
Operational Warning Lights
System A & B Pressure Filter Condition LED Warning Indicator for Clogged Conditions
Kidney Loop Pump Filter Condition LED Warning Indicator
Reservoir Low Level LED Warning Indicator
High Fluid Temperature LED Warning Indicator
Reservoir Kidney Loop Pump
Continuously Filters Fluid
Continuously Cools Fluid
Seven Digital Pressure Gauges (.25% Accuracy)
System A Supply Pressure
System B Supply Pressure
Return Back Pressure
Low Independent Pressure Gauge
Medium Independent Pressure Gauge
High Independent Pressure Gauge
Intensifier Pressure Gauge
Safety Features
Two Ergonomically Located Emergency Stop Switch
Safety Over Pressure Relief Valve for Both System A & B
Safety Drip Pan Completely Covers Bottom to Ensure Clean Floors
All Electrical Components Installed in NEMA 4, 12 Enclosure
All Gauges are Fully Enclosed in NEMA 4, 12 Enclosure with a Clear Front Safety Glass Cover
Operational LED Warning Indicator Lights
Dual Heavy Duty Floor Locks to Ensure Stability
Optional Safety Glass Sliding Doors for Work Sink
Return Back Pressure for Dynamically Loading Components
Return Back Pressure By-Pass Valve
Return Back Pressure, Pressure Adjustment Valve
Return Back Pressure, Pressure Gauge
Return Back Pressure Flow Meter
System B
Oilgear Pump
Lincoln Motor
Complete Pressure Adjustment (450 - 5000 PSI)
Complete Flow Adjustment (0 - Full GPM)
Pressure and Return Ports
Digital Pressure Gauges (.25% Accuracy)
Digital Supply and Return Flow Meters (1% Accuracy)
Safety Over Pressure Relief Valve
By-Pass Dump Valve
Pump Flow Control Valve
Pump Pressure Control Valve
Five Pumps
Oilgear System A Pressure Compensated Pump
Oilgear System B Pressure Compensated Pump
S/C High Pressure Intensifier Pump (10,000 PSI)
Work Sink Drain Pump
Reservoir Kidney Loop Pump
4-Way Directional Flow Control Valve
Manually Operated 4-Way Directional Flow Control Valve with Complete Flow Control to Either Port A or Port B
3 Each Stand Alone No Shock Pressure Gauges
Over Pressure Gauge Savers on All Gauges
Five Digital Flow Meters (1% Accuracy)
System A Pump Supply Flow
System B Pump Supply Flow
System A Return Flow
System B Return Flow
Low Range (.4 - 7 GPM)
Air Over Oil Intensifier
Digital Pressure Gauge (.25% Accuracy)
Air Shut-Off Valve
Air Regulator
Safety Over Pressure Relief Valve
By-Pass Dump Valve
Dedicated Port
Automatic Oil Temperature Control
Panel Mounted Oil Temperature Set Point
Digital Oil Temperature Gauge
Additional Features
All Welded, 14 Gauge B3 (Brushed Finish) Stainless Steel Cabinet
Illuminated Work Area Provided By Overhead Sink Light
Test Port for all Pressure Gauges
Easy Access Exterior Fluid Sampling Valve to Meet Quality Parameters
Safety Drip Pan Completely Covers Bottom
Work Sink with Perforated Metal Grating
Heavy Duty All Welded 1/4" Thick Wall Tubing Frame with Fork Lift Brackets
Easy Maneuvering Ensured By Two Fixed and Two Swivel Castors with Stability Provided by the Heavy Duty Floor Lock
Work Sink Drain Pump with Filter (4 GPM)
Durable Laser Engraved, Aluminum Placards
Panel Mounted Operational Instructions
Current Pressure Gauge and Flow Meter Certificates of Calibration
