• AI-assisted performance analytics

• Fully enclosed noise-reduction casing

• Wireless connectivity for remote monitoring

• Dual-stage pressure regulation

Single System

• Complete Pressure Adjustment (450 - 5000 PSI)

• Complete Flow Adjustment (0 - Full GPM)

• Pressure and Return Ports

• Digital Pressure Gauges (.25% Accuracy)

• Digital Supply and Return Flow Meters (1% Accuracy)

• Safety Over Pressure Relief Valve

• By-Pass Dump Valve

• Pump Flow Control

• Pump Pressure Control

High Pressure Hand Pump

• Digital Pressure Gauge (.25% Accuracy)

• Pressure Release Valve

• Dedicated Port

Two Digital Flow Meters (1% Accuracy)

• Pump Supply Flow

• Return Flow

Operational Warning Lights

• Pressure Filter Condition LED Warning Indicator for Clogged Conditions

• Kidney Loop Pump Filter Condition LED Warning Indicator

• Reservoir Low Level LED Warning Indicator

• High Fluid Temperature LED Warning Indicator

• Stand Alone No Shock Pressure Gauges



Reservoir Kidney Loop Pump

• Continuously Filters Fluid

• Continuously Cools Fluid

Safety Features

• Ergonomically Located Emergency Stop Switch

• Safety Over Pressure Relief Valve

• Safety Drip Pan Completely Covers Bottom To Ensure Clean Floors

• All Electrical Components Installed in NEMA 4, 12 Enclosure

• All Gauges are Fully Enclosed in NEMA 4, 12 Enclosure with a Clear Front Safety Glass Cover

• Operational LED Warning Indicator Lights

• Dual Heavy Duty Floor Locks to Ensure Stability

• Optional Safety Glass Sliding Doors for Work Sink

4-Way Directional Flow Control Valve

• Manually Operated 4-Way Directional Flow

• Control Valve with Complete Flow Control

Four Pumps

• Oilgeari Pressure Compensated Pump

• High Pressure Hand Pump (10,000 PSI)

• Work Sink Drain Pump

• Reservoir Kidney Loop Pump

Instrumentation

• All Gauges Feature Easy Programmability for Field Calibration

Four Digital Pressure Gauges (.25% Accuracy)

• Pump Supply Pressure (6000 PSI)

• Hand Pump (0 - 10,000 PSI)

• Medium Isolated Pressure Gauge

• High Isolated Pressure Gauge

Stand Alone No Shock Pressure Gauges

• Over Pressure Gauge Savers on all Gauges

Automatic Oil Temperature Control

• Panel Mounted Oil Temperature Set Point

• Digital Oil Temperature Gauge

Super Clean Filtration - Industry Leading Filtration Ensures Quality While Increasing Aircraft Component Life

• High Efficiency, Non-Bypass Pressure Filter (3 Micron Absolute)

• Reservoir Kidney Loop Filter (3 Micron Absolute)

• Sink Drain Filter (3 Micron Absolute)

• Pump Case Drain Filter (6 Micron Absolute)

Additional Features

• All Welded, 14 Gauge B3 (Brushed Finish)

• Stainless Steel Cabinet

• Illuminated Work Area Provided By Overhead Sink Light

• Test Port for all Pressure Gauges

• Easy Access Exterior Fluid Sampling

• Safety Drip Pan Completely Covers Bottom

• Work Sink with Perforated Metal Grating

• Heavy Duty All Welded 1/4" Thick Wall Tubing

• Frame with Fork Lift Brackets

• Easy Maneuvering Ensured By Two Fixed and Two Swivel Castors with Stability Provided by the Heavy Duty Floor Lock

• Work Sink Drain Pump with Filter (4 GPM)

• Durable Laser Engraved Aluminum Placards

• Panel Mounted Operational Instructions

• Certificates of Calibration
