• Dual independent hydraulic systems

• Built-in temperature regulation

• User-friendly control panel

• Real-time performance monitoring

Monitoring System with Data Acquisition

• Will Save Time and Money

• Insure Compliance with FAA Regulations and OEM Test Requirements

• Provides a Convenient and Easy to Understand Method of Testing and Reporting

• Produces Accurate Records for Stored Data for FAA Audit Compliance and Accountability

• Eliminates Hard to Support Component Testing Procedures

• Easy to Interpret Strip Chart That Displays Pressure, Flow and Temperature Simultaneously

Five Pumps

• Oilgear Pressure Compensated Pump

• High Pressure Hand Pump (10,000 PSI)

• Work Sink Drain Pump

• Automatic Nano Filtration Pump

Super Clean Filtration

• High Efficiency, Non-Bypass Pressure Filter (3 Micron Absolute)

• Reservoir Kidney Loop Filter (3 Micron Absolute)

• Sink Drain Filter (3 Micron Absolute)

• Exclusive Automatic Nano Filtration System (.25 Micron Absolute)

Calibration

• Calibration parameters are stored in the electronic interface and the software automatically reads the calibration parameters from the device when launched

• Operator can adjust the sensor parameters during calibration for the correct accuracy needed

Software Includes

• Viewing of Graph History

• Displaying and Hiding of Individual Graph Plots

• Adjusting Graph Scale

• Changing Alarm History

• Data Acquisition

Reservoir Kidney Loop Pump

• Continuously Filters Fluid

• Continuously Cools Fluid

• Automatic Oil Temperature Control

Additional Features

• All Welded, 14 Gauge B3 (Brushed Finish) Stainless Steel Cabinet

• Illuminated Work Area Provided By the Overhead Work Sink Lights

• Easy Access Fluid Sample Port to Meet Quality Parameters

• Guaranteed No Leaks

• Safety Drip Pan Completely Covers Bottom

• Work Sink with Perforated Metal Grating

• Heavy Duty All Welded 1/4" Thick Wall Tubing Frame with Fork Lift Brackets

• Easy Maneuvering Ensured By Two Fixed and Two Swivel Castors with Stability Provided By the Heavy Duty Floor Lock

• Work Sink Drain Pump with Filter (4 GPM)

• Durable Laser Engraved Aluminum Placards

• Panel Mounted Operational Instructions

• Current Pressure Gauge and Flow Meter

• Certificates of Calibration

General Features

• Panel Mounted Pump Controls for Ease of Operation and Safety

• Safety Glass Sliding Doors with Tempered Glass with Heavy Duty Door Rollers and Rails

• Complete Pump Pressure Adjustment (450 – 5000 PSI)

• Complete Pump Flow Adjustment (0 – Full GPM)

High Pressure Hand Pump

• Digital Pressure Gauge (.25% Accuracy)

• Pressure Release Valve

• Dedicated Port

4-Way Directional Flow Control Valve

• Electrically Operated with Port Indicator Lights for Testing Cylinders

Software Parameters

• Main screen displays strip chart enabling the hydraulic technician to have a more in-depth understanding of the operation/test procedure and troubleshooting of the component under test.

• Color coding of the parameters are easily read.

Operational Warning Lights

• Pressure Filter Condition LED Indicator

• Kidney Loop Pump Filter Condition LED Indicator

• Reservoir Low Level LED Warning Indicator

• High Fluid Temperature LED Warning Indicator

• Nano Filter Condition LED Warning Indicator

Oil Polishing System

• Extremely Clean Nano Filtration with Automatic Timer and Operation LED Warning Indicator

Safety Features

• High and Low Pressure Alarm

• High and Low Flow Alarm

• High and Low Oil Temperature Alarm

• System By-Pass Relief Valve (7500 PSI)

• Safety Glass Doors to Protect Operator

• Isolated Work Sink – No Hydraulic Controls Located Within Sink Area
