• Digital precision calibration

• High-accuracy gauge readings

• Rugged portable case

• Industry-standard certification

general features

• Convenient 'Hands Free' Operation

• Foot Control for Pump Output Pressure

• Air Over Oil Intensifier Pump

• Operates Off Shop Air (100 PSI - 15 CFM)

• High or Low Pressure System Selector Valve

• High Pressure Range Dedicated System

• Precise High Pressure Adjustment (5,000 PSI or 10,000 PSI)

• Low Pressure Dedicated System

• Precise Low Pressure Adjustment (0 - 200 PSI)

• All Welded, .009 Brushed Aluminum Cabinet

• Easy Maneuvering Ensured by Two Fixed and Two Swivel Castors with Stability Provided by the Heavy Duty Floor Lock

• Large Capacity Return Filter (3 Micron Absolute)

• Work Sink Drain (18" x 42")

• Stainless Steel Reservoir (5 Gallons)

• Inlet Shop Air, Dryer & Lubricate

• High Pressure Port

• Low Pressure Port

• Return Port

• Guaranteed No Leaks

• Safety Pan Completely Covers Bottom

• Durable Laser Engraved, Aluminum Placards

• Panel Mounted Operational Instructions

• Easy Access Exterior Fluid Sampling

• Valve to Meet Quality Parameters

instrumentation

2 each 4" Test Quality Pressure Gauge (.25% Accuracy)

• High Pressure Low Pressure (0-200 PSI)

• Selector Valves for High or Low Pressure System

• Gauges Incorporate Adjustable Dial Indicator for Easy Recalibration

• Current Pressure Gauge Certificate of Calibration
