Precise digital pressure gauges
100% duty cycle operation
Temperature monitoring system
General Features
High Pressure Piston Pump
Electric Starter with Oversized Battery
Complete Pump Pressure Adjustment (0 - 1800 PSI)
Complete Pump Flow Adjustment
All Models Have a Maximum Pressure of 4000 PSI
High Pressure Piston Pump Will Produce 4000 PSI at Reduced Flows
High Pressure, Dual Scale Flow Meter (4% Accuracy)
4" Liquid Filled Pressure Gauge (1% Accuracy)
High Pressure Oil Temperature Gauge
By-Pass Dump Valve
High Efficiency, Non-Bypass High Pressure Filter (3 Micron Absolute)
Large Capacity Return Filter (6 Micron Absolute)
Reservoir Selector Valves (To Use Either Aircraft's (Closed Loop) or Unit's Reservoir (Open Loop))
Heavy Duty Oil Cooler with Fan
Stainless Reservoir (12 gal capacity)
Standard #8 Pressure Hoses and #12 Return Hoses, 15 ft. (4.5 m) Long
Current Pressure Gauge and Flow Meter Certificate of Calibration
Solid, Puncture Proof Wheels, Guaranteed No Flats
All Welded Steel Tubing Frame
Panel Mounted Controls for Ease of Operation and Operator Safety
