Stainless steel construction Precise digital pressure gauges 100% duty cycle operation Temperature monitoring system
Performance Assured 100% Duty Cycle
Will Deliver Maximum Flow @ Maximum Pressure
Industrial Duty Lincoln Motor
Heavy Duty Motor Starter with Over Load Protection
Super Clean Filtration
High Efficiency, Non-Bypass Pressure Filter (3 Micron Absolute)
Large Capacity Return Filter (6 Micron Absolute)
Instrumentation
High Pressure Dual Scale Flow Meter (4% Accuracy)
Test Quality 6" Pressure Gauge (1% Accuracy)
Dual Scale Pyrometer / Oil Temperature Gauge (2% Accuracy)
Hour Meter
Standard Features
Weather Proof Cabinet
Easy Maneuverability Between Hangars Provided by the Heavy Duty Trailer with Tow Bar and Brake
Solid Tires Guaranteed to Never go Flat
100% Duty Cycle, Will Deliver Maximum Flow @ Maximum Pressure
All Welded 0.90 Aluminum Construction
Heavy Duty All Welded Frame with Fork Lift Tubes
Removable Top Panels and Rear Door for Ease of Access to Unit's Components
High Efficiency Aluminum Oil Cooler with 3 Phase Electric Fan
Stainless Steel Reservoir (120 Gallons)
All Electrical Components Installed in Liquid Proof Enclosure (NEMA 4, 12)
Safety Assured Exterior Electrical Panel Access
Current Pressure Gauge and Flow Meter Certificate of Calibration
Reservoir Selector Valve (To Use Either the Aircraft's or Unit's Reservoir)
Standard #16 Pressure Hoses and #24 Return Hoses, 25 ft. (7.62 m) Long
Standard 50 ft. (15.2 m) Electrical Input Cable
Durable Laser Engraved, Aluminum Placards
Panel Mounted Operational Instructions
Easy Access Exterior Fluid Sampling Valve to Meet Quality Parameters
Heavy Duty Stainless Steel Bracket for Hose and Electrical Input Cord Storage
Reservoir Sight Glass to Ensure Safety
Extra Capacity Reservoir Desiccant (Water Absorbing) Breather
Panel Mounted Controls
Complete Pump Flow Adjustment (0-Full GPM)
Complete Pump Pressure Adjustment (250-Full PSI)
By-Pass Dump Valve
Operational Warning Lights
Pressure Filter Condition LED Warning Indicator for Clogged Conditions
High Fluid Temperature LED Warning Indicator
Sturdy Weather Resistant Construction
Durable 0.90 Brushed Aluminum Cabinet Construction
Large Front Hinged Door Provides Protection for Instrumentation and Controls
Large Rear Hinged Access Door Provides Convenient Access and Inspection
Removable Top Panel for Ease of Access to Unit's Components
No Exterior Paint to Fade or Chip with Usage
Guaranteed Not to Rust
Heavy Duty Frame with Fork Lift Tubes
16" Solid Wheels - Guaranteed No Flats
Easy Maneuverability Between Hangars Provided by the Heavy Duty Trailer with Tow Bar and Brake
