Stainless steel construction
Precise digital pressure gauges
100% duty cycle operation
Temperature monitoring system
System A
Complete Flow Control (0-Full GPM)
Complete Pressure Control (250 - Full GPM)
Variable Area Flow Meter (2% Accuracy); Optional Digital Flow Meter (1% Accuracy) Available
Test Quality Pressure Gauge (1% Accuracy); Optional Digital Pressure Gauge (.5% Accuracy) Available
Standard Features
Independent Dual System Includes:
Independent Dual Motors
Independent Dual Pumps
Independent Dual Flow Meters
Independent Dual Pressure Gauges
Independent Dual Flow and Pressure Control Valves
Independent Dual By-Pass Dump Valves
Dual Pressure Hoses (25 Ft. Long)
Dual Return Hoses (25 Ft. Long)
100% Duty Cycle, Will Deliver Maximum Flow @ Maximum Pressure
Electric Reservoir Fill Pump System
High Efficiency Aluminum Oil Cooler with 3 Phase Electric Motor
Stainless Steel Reservoir - Capacity 150% of Rated Maximum Flow
All Electrical Components Installed in Liquid Proof Enclosures (NEMA 4, 12)
Extra Capacity, Reservoir Desiccant (Water Absorbing) Breather
Heavy Duty Frame with Fork Lift Tubes
Standard 50 ft. (15.2 m) Electrical Input Cable
Guaranteed No Leaks, Stainless Steel Pan, Completely Covers Bottom
Durable Laser Engraved, Aluminum Placards
Panel Mounted Operational Instructions
Current Pressure Gauge and Flow Meter Certificate of Calibration
Easy Access Exterior Fluid Sampling Valve to Meet Quality Parameters
Instrumentation
Dual Variable Area Flow Meters (4% Accuracy)
Optional Dual Digital Flow Meters (1% Accuracy) Available
Dual Test Quality Pressure Gauges (1% Accuracy)
Optional Dual Digital Pressure Gauges (.5% Accuracy) Available
All Optional Digital Gauges Installed in Skydrol Resistant Enclosure
Dual Scale Pyrometer / Oil Temperature Gauge (1% Accuracy)
Optional Digital Pyrometer / Oil Temperature Gauge Available
Hour Meter with Maintenance Reminder Warning Light
Super Clean Filtration
Oil Polishing Nano Filtration System (.25 Micron Absolute)
Dual, High Efficiency, Non By-Pass Pressure Filter (3 Micron Absolute)
Dual Large Capacity Return Filter (6 Micron Absolute)
Dual By-Pass Filter (6 Micron Absolute)
Dual Pump Case Drain Filters (6 Micron Absolute)
System B
Complete Flow Control (0-Full GPM)
Complete Pressure Control (250 - Full GPM)
Variable Area Flow Meter (2% Accuracy); Optional Digital Flow Meter (1% Accuracy) Available
Test Quality Pressure Gauge (1% Accuracy); Optional Digital Pressure Gauge (.5% Accuracy) Available
Durable 14 Gauge Stainless Steel Cabinet Construction
Large Hinged Rear Access Door Provides Convenient Access and Inspection
Removable Top Panel for Ease of Access to Unit's Components
No Exterior Paint to Fade or Chip with Usage
Guaranteed Not to Rust
Reservoir Fill Pump System
For Servicing Aircraft's Reservoir (4 GPM)
Operational Warning Lights
Dual Pressure Filters Condition LED Warning Indicators for Clogged Conditions
Dual Return Filter Condition LED Warning Indicators for Clogged Conditions
High Fluid Temperature LED Warning Indicator
Reservoir Low Level LED Warning Indicator
Operational Beacon
Nano Filter Condition LED Warning Indicators for Clogged Conditions
Dual By-Pass Filters Condition LED Warning Indicators for Clogged Conditions
Pump Cavitation LED Warning Indicator
